Compact Broadband
A compact, mission-ready blade antenna. Balances portability with wideband performance for VHF/UHF tactical radios. Submersible and snag-resistant.
Mil-Spec
Rugged Blade Design
Engineered for harsh environments, this 13.25" antenna features a flexible blade construction that shrugs off impacts and reduces snag hazards compared to rigid whips.
NSN 5985-01-559-4696
RF Specifications
-
Range: 30–512 MHz
-
Height: 13.25 Inches (Erect)
-
Power: 8W CW
-
VSWR: ≤ 3.5:1
Environmental
-
Submersible to 20 Meters
-
Salt Fog & Sand Resistant
-
Flexible Blade Construction
-
Made in USA
Radio Interface: TNC
Designed for military transceivers utilizing standard TNC threaded antenna ports.
Compatible Models:
- AN/PRC-152
-
AN/PRC-148
- PRC-163
Tactical Application
Ideal for direct radio attachment where profile reduction is key, or for use with relocation kits on plate carriers. Also frequently used with spectrum analyzers.
Direct Connect Maritime Ops Relocation Kits
Included: 1x 13" Blade Antenna.
Mission Specs
-
50 Ohms Nominal Impedance
-
Waterproof (20m Submersible)
-
Compact 13" Profile
-
Matte Black Finish
-
Made in USA
Connector Verification
This antenna features a TNC Male connector. It connects directly to military radios (PRC-152/148). It will NOT fit Baofeng or Yaesu SMA radios without an adapter. Baofeng handhelds use SMA-Male radio ports (SMA-Female antennas); many Yaesu HTs use SMA-Female radio ports.
Warranty
DISCO32 limited warranty — 1 year from original purchase for defects in materials and workmanship under normal use. Support starts with a troubleshooting ticket at help@disco32.com.
